Motorola Moto Z Play

Completion and design. Inside the box is a standard set for a modern gadget: a clip, instructions, a Type-C charger and a back panel. It should be noted that the clip differs from those that we are accustomed to seeing. Its needle is longer, so do not lose it, otherwise you can not remove the SIM card. The device dimensions are as follows: length - 156.4 mm, width - 76.4 mm, height - 7 mm. The model weighs 136 g.

Screen. Alas, this side of the device is not strong. The image is pale, when watching a video it's not so noticeable. When tilted, the white color goes somewhere in the green. For an ordinary user, this will not be a problem, but competitors are much better with this. However, an indispensable advantage is the duration of the smartphone, which was achieved not without the merit of the display. So for the screen a small plus in karma. The diagonal is 5.5 inches, the resolution is 1920x1080, nothing new.

Characteristics and performance. Since this is the youngest model, it has less appetite. Therefore, the device was equipped with a Qualcomm Snapdragon 625 processor and 3 GB of RAM. For the processing of graphics meets video chip Adreno 506. Fans of games will not be offended: the smartphone pulls many modern games. There is a slot for a memory card format MicroSD, the model itself has on board 32 GB.

Autonomy. The battery does not hit with its volume, only 3510 mAh, but do not look at this figure, with the autonomy of the smartphone everything is in order. He lives 2 days with the condition that you use WI-FI, 3G, actively call, send messages and play an hour a day. If all this is not done, then 3 days without charging you provided.

Multimedia. The main camera is 16 megapixels without optical stabilization, and the front camera is 5 megapixels. Images on the main camera are good for the average user, at night things are worse. If you are not a photographer by profession, then the camera will suit you. Front camera it is better to use for video calls, the quality of pictures on it is lame.

Operating system. Here you can not write much, because the smartphone is running Android 6.0 with a few additions from the company itself.

Motorola Moto M

Design and equipment. As with the previous model from our review, in the box only all the most necessary: charging, USB Type-C cable, headphones, documentation. But thank you, everything you need is freely available and you can buy it later. Dimensions of the gadget: length - 151.35 mm, width - 75.35 mm, height - 7.85 mm. The model weighs 163 g.

The screen at the gadget is good. The diagonal of the IPS matrix is 5.5 inches, Resolution: 1920x1080 pixels. There is an oleophobic coating, so that dirt will appear, but it can not be wiped off. On the street even in sunny weather no problems with use.

Autonomy and performance. As it was stated at the beginning, the processor from the company MediaTek, namely MediaTek Helio P10 (MT6755) with a frequency of 1.8 GHz, is on board the smartphone. The graphics are processed by the Mali T860 MP2. RAM 3 GB, for comfortable use of the smartphone is enough. There is a slot for the memory card. The battery capacity is 3050 mAh. The internal memory in the smartphone is 32 GB, which is quite good considering the possibility of installing an optional memory card.

Multimedia. The main camera is 16 megapixels, there is a double LED flash and a phase autofocus. The maximum recording resolution is 1080 p. The photos are of normal quality, but there are problems with focusing. Front camera at 8 MP, moving objects are given to her badly. The volume of the speaker is sufficient for conversations, the microphone is OK.

Operating system. The device is running Android 6.0. Installed only the most necessary, so that the user can then download himself, what he needs. The interface works smoothly (we say thanks to 3 GB of RAM).

Motorola Mobile Phone Schematics PDF look this page.

Motorola Moto G4 Plus

Design and equipment. This time, Motorola is a bit generous with the bundle, so we can see beyond the standard set of charging, instructions and the box itself - a storage device. It should be noted that only this model was distinguished by the presence of a charger. Since the model is from the middle price category, it is not necessary to look for innovation in the design. Below in the square frame is a fingerprint scanner, more reminiscent of a button. However, clicking on it is useless, it's a scanner. Buttons back and no home, everything is displayed.

Display. The size is 5.5 inches, the resolution is 1920x1080. IPS matrix with a density of 401 PPI. Oleophobic coating is available. The very same picture looks bright and high-quality, when the device tilts the colors remain the same, no distortion. In sunny weather, the information on the screen remains readable (thanks to a good margin of brightness).

Dimensions. Length - 153 mm, width - 76.6 mm, height - 7.9 mm. The model weighs 155 g.

Performance. For most users, the possibilities of Moto G4 Plus will suffice with the head. The model is equipped with a Qualcomm Snapdragon 617 processor at 1.5 GHz and an Adreno 405 graphics chip. The RAM is installed in standard 2 GB. The built-in memory is 16 GB + the ability to install a memory card up to 128 GB. In practice, in the games the device proved to be good, many popular novelties go without problems. With autonomy, the smartphone is in complete trouble. The battery capacity is 3000 mAh. In the stress tests it showed itself badly, everyone expected a much better result. When making a cyclic video, the smartphone was enough for 9 hours.

Multimedia. Like most modern models, the G4 Plus has a main and front camera at 16 and 5 Mp respectively. The main camera with 1 / 2.4-inch sensor OmniVision PureCell Plus and aperture f / 2.0. Has a phase detection system and optical autofocus. For those who are far from all these technical terms, let's just say - the images are qualitative.

Operating system. With the OS all right - all the same Android 6.0, nothing superfluous, except for 2-3 programs. The user himself sets everything that he needs for further work.

Motorola Moto X Play

Design and equipment. On the complete set - a charger, a special clip for retrieving Sims and paper. The headset will have to be bought separately. There is a slot for the second sim card. The device can not be called comfortable or uncomfortable with confidence - it is rather something average, but the form is made so that it lies in the hand nicely. The surface of the cover is rubberized, so you can not be afraid that the phone will fly out of your hands. The choice of 2 colors - white and black, but in the shops are sold separately pads with different colors. A little annoying rocker volume: it is not quite tightly installed and produces an unpleasant sound when pressed. Dimensions of the device: length - 148 mm, width - 75 mm, height - 8.9 mm. The model weighs 169 grams.

Display. The screen size is 5.5 inches, resolution: 1920 x 1080, the picture is colorful, clear, in general pleases the eye. The pixel density is 403 PPI. At an angle of color is not distorted, and in the street the reserve of brightness is enough to use a telephone on a sunny day. Also in the settings there are 2 color modes.

Performance. The device is Qualcomm Snapdragon 615 with video chip Adreno 405. The amount of RAM is standard for smartphones in this category - 2 GB. For this cost, you could throw another 1 GB. The model is almost not heated, only with very complex tasks it becomes warm. Games go without problems on average settings. The capacity of the battery is 3630 mAh. If you do not load the device with complex tasks, then the time will be a day, a half. Built-in 16 GB memory, there is an option to insert a memory card up to 128 GB.

Multimedia. The camera uses a Sony (Manuals PDF page) 21-megapixel sensor. A good solution, removes soundly (FullHD, unfortunately, is not provided), the pictures are of high quality, but at night the quality falls. Frontal camera 5 megapixels can not boast anything. Ordinary users will be very pleased, but professionals should not recommend it to photographers.

Operating system. Android 6.0 without any pre-installed programs, except Moto Display. That is, when you take the phone into your hand, you will see all missed calls and letters. This does not affect the battery performance at all. Voice search from Google works fine.
